All-In-One Solar Street Light
DOUBLE GLASS MODEL
The SunMaster Double Glass Model represents the next generation of solar street lighting—combining cutting-edge performance with enhanced durability. This all-in-one system integrates high-efficiency TopCon N-type monocrystalline solar panels with double glass encapsulation, LiFePO₄ long-life batteries, and high-output Philips/Bridgelux LED chips, all in a compact, vandal-resistant body.
Available in power options from 30W to 120W, this model delivers up to 180 lm/W and provides 10–14 hours of lighting per night with a 3–5 day battery backup. The double glass solar module offers improved resistance to weathering and potential-induced degradation (PID), ensuring consistent performance even in extreme environments.
With optional motion sensors, remote/cloud-based monitoring, and a fast 10-minute installation process, the Double Glass Model is the ideal solution for long-term, low-maintenance lighting across roads, parks, pathways, and off-grid areas.
All in One Solar Street lights Benefits
Quick and easy 10min installation without any wiring
Monocrystalline solar module >20% efficiency
QEDGE web-based wireless controls, monitoring & management system
Dual Lithium LiFePO4 patented battery management system with 10+ year performance
Advanced LED lighting including PIR Motion Sensor
Modular design with fully integrated components
Technical Highlights of the SunMaster All-In-One Solar Street Light Double Glass Model
From 30W to 120W
The Double Glass Series from SunMaster offers an integrated, high-performance solar lighting solution designed for durability and efficiency. Available in 30W, 60W, 80W, 100W, and 120W variants, each unit features Philips or Bridgelux LED chips with a lifespan exceeding 100,000 hours and luminous efficacy of over 180 lm/W (LM-79 tested). Light distribution options include Type II, III, and IV, with a color temperature range of 3000K–6500K and CRI ≥70.
The solar module uses TopCon N-type monocrystalline cells with dual-glass encapsulation, achieving >22.8% efficiency and rated power up to 150Wp, depending on the model. Energy is stored in high-capacity LiFePO₄ batteries (307–922Wh), offering 3–5 days of autonomy, >3000 charge cycles, and minimal self-discharge (<2% per month).
Equipped with MPPT controllers, built-in high-efficiency LED drivers, and optional APP or wireless remote monitoring, these lights offer dusk-to-dawn operation with programmable dimming and motion sensing. The robust aluminum housing provides IP65 and IK10 protection, making it suitable for harsh outdoor conditions.
Designed for pole or wall mounting, the Double Glass Series is ideal for street lighting, perimeter security, parking areas, and remote infrastructure.
Built to Last. Powered by the Sun.
The SunMaster Double Glass Series is more than just a lighting solution—it’s a long-term investment in energy efficiency, reliability, and sustainability. Engineered with premium materials, advanced solar technology, and intelligent controls, it delivers consistent performance even in the harshest environments.
Whether you're upgrading urban infrastructure or powering off-grid locations, this system offers everything you need: fast installation, zero electricity costs, minimal maintenance, and full peace of mind.
Contact SunMaster today to discover how the Double Glass Series can elevate your next lighting project—with smart, solar-powered innovation that works wherever you need it.
